Industrial Metal Structure Warehouse Lightweight Steel Construction Warehouse

Basic Information

Place of Origin:	China
Brand Name:	Lanjing
Certification:	ICR Polska/VC/HS221231
Model Number:	LANJING-1

Minimum Order Quantity:	1000sqm
Price:	1000-1500 Square Meters $45-50；1500-2000 Square Meters $42-45；2000-3000 Square Meters $40-42；
Delivery Time:	30-45 days
Payment Terms:	TT
Supply Ability:	30000T/year

Get Best Price Contact Now

Name:	Metal Structure Warehouse	Dimensions:	Customers' Requirement
Working Scope:	Design,Fabrication, Installation	Wall And Roof:	Glass Wool Sandwich Panel
Design Style:	Contemporary	Structure Form:	Portal Steel Structure
Connection:	Bolt Connection And Welded Connection	Sail Finishing:	PVDF/PTFE, Pvc Coated
Highlight:	Industrial Metal Structure Warehouse , Metal Structure Warehouse Lightweight , Lightweight Steel Construction Warehouse

Product Details

Specification

 Steel - structured buildings are different from traditional ones. They're made entirely of steel. The structure is made up of steel beams, columns, trusses, and other parts. These parts are made from section steel and steel plates, and they're connected by welding, bolts, or rivets.Steel - structured buildings are light and simple. That's why they're used a lot in big factories, stadiums, and very tall buildings. There are several types of steel - building structures, like the portal rigid steel frame, frame structure, truss structure, and grid structure.Here are the features and uses of these standard steel - building structures:Portal frame structures are easy to understand in terms of how they handle force.
 The way force moves through them is clear, and they can be built quickly. We can see them in many industrial and regular buildings, like factories, shops, and places for culture and entertainment.Steel - building frame structures are flexible. They can create big spaces inside. So, we often find them in multi - story and tall buildings such as office buildings, shopping malls, and conference centers.Steel truss structures use small - cross - section tubes to make bigger parts. They're great for buildings that need a large space or are very tall, like big roofs, bridges, towers, and oil platforms at sea.Steel grid structures are made of many rods arranged in a certain way. They don't have much stress in space, they're light, very strong, and can stand up well to earthquakes. They're used for things like gyms, exhibition halls, gas stations, and hangars.

Material Description

Main Structure	Including Column & Beam, Made of welded H section Steel, Steel Grade Q355B/Q235B
	Column & Beam Connection: High Strength Bolt
	Column & Foundation Connection: Pre-embedded Anchor Bolt
Secondary Structure	Roof Purlin & Wall Purlin: C-shape or Z-shape Steel
	Knee Brace: Angle Steel
	Brace: Steel Rod
	Tie Bar: Steel Pipe

Types of wall panels and roof panels	Applicable Regions and Scenarios
Color Steel Sheet	Areas without winter, preferred for processing workshops and warehouses
Color Steel Sheet & Fiberglass Roll Insulation	Areas with winter but with low requirements of temperature , preferred for warehouses and workshops
Insulated Sandwich Panel	Workshops and warehouses with temperature requirements
PU Insulated Sandwich Panel	Workshops, warehouses and public facilities with high requirements of temperature for the working environment

Product packaging

1. What kind of customer service do you provide?
We offer comprehensive customer service, including basic design,supporting facilities procurement, and the option to dispatch installation guidance.

2. How about the customer reviews of your company?
We are proud to have received consistently high five-star reviews from our customers, which stand as a testament to our commitment to quality and service.

3. What is your quality inspection process like?
Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished goods, each stage is meticulously inspected to guarantee superior quality.

4. Can you send engineers or a whole team to install my project?
We will give detailed installation drawings for free. We can send engineers as an installation director or a team upon request.

5. Do you accept container loading inspection?
You are welcomed to send an inspector, not only for the container loading, but any time during the production time.

6. Do you offer designing service for us?
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial buildings like office mansions, super markets, auto dealer shops, shipping malls, 5-star hotels.

7. What is the delivery time?
Delivery time depends on order quantities. In general, the delivery time to the nearest seaport in China will be 40 days after
receiving the deposit.

8. How can I get a quotation for my projects?
You can contact us by email, phone,  Trade manager and so on 24*7 and you will get a reply within 8 hours.

9. What certifications has your company passed?
Our company has passed professional certifications such as IOS9000, CE, and SGS, ensuring that our products and services meet international standards.
