Clear Span Metal Buildings Workshop , Customized Light Steel Frame Commercial Building

Basic Information

Place of Origin:	China
Brand Name:	LANJING
Certification:	ICR Polska/VC/HS221231
Model Number:	LANJING-01

Minimum Order Quantity:	1000sqm
Price:	35-55$/sqm
Delivery Time:	30-45 days
Payment Terms:	TT
Supply Ability:	30000T/year

Get Best Price Contact Now

Features:	Steel Structure For Auto Service Shop	Name:	Steel Prefabricated Building Structure
Front Wall:	Glass Facade	Tolerance:	±1%
Design Paramet:	Wind Load, Snow Load And Earthquake	Item Name:	Steel Structure Factory
Design:	Custom Exactly As The Demands	Service Life:	50 Years
Doors:	Roller Shutter/Swing/Sliding	Color:	Customer's Requirement
Roof Cladding:	Corrugated Steel Sheet/Sandwich Panel	Sail Finishing:	PVDF/PTFE, Pvc Coated
Crane Capacity:	5Tons*2 Pcs	Structure Type:	Light Steel Structre
Frame:	Weld Steel Structure Frame	Material:	Steel
Price Term:	FOB CIF CFR EXW	Cladding:	Steel Color Sheet
Design Software:	Auto CAD,Teckla	Bracing:	Round Bar/Angle Steel/Steel Rod
Lifespan:	More Than 50 Years	Downpipe:	UPVC
Life Time:	50 Years
Highlight:	Clear Span Metal Buildings Workshop , Light Steel Prefabricated Building Structure , Customized Steel Frame Commercial Building

Steel Structure Warehouse Maximizing Space Utilization With Clear Span Design

Product Details

Specification

Steel Structure Warehouse Maximizing Space Utilization With Clear Span Design

Compared with traditional buildings, steel structure buildings are a new type of building structure form, where the

entirebuildingis constructed using steel. Its structure mainly consists of components made from section steel and

steel plates,such as steelbeams,steel columns, and steel trusses. The components are connected through welding,

bolts, and rivets. Due to their light weight and simple construction, steel structure buildings are widely used in large

factories,sports venues, super high-rise buildings, and otherfields. Types of steel structure buildings include portal

frames, frame structures, truss structures, and gridstructure.Characteristics and applications of common types of

steel structure buildings: Portal frame structures have simple force application and clear load transfer paths, and

fast construction speed. They are widely used in industrial and civil building fields such as industrial plants,

commercial buildings, cultural and entertainment public facilities.Steel frame structures have strong flexibility and

can create larger spaces, often used in multi-story and high-rise buildings such as commercial office buildings,

shopping malls, and conference centers. Steel truss structures use small-section pipes to form larger-section

components and are commonly applied in industrial and civil buildings that require large spans or heights, such as

long-span roofs, bridges, tall towers, and off shore oil platforms. The steel grid structures are highly indeterminate

spatial structures composed of many rods according to specific rules.They have low spatial stress, light weight,

great stiffness, and excellent seismic performance, suitable for buildings like stadiums, exhibition halls, gas stations,

and hangars. The above-mentioned steel structures, as an efficient, safe, and sustainable building structure form,

will play an important role in thefuture of construction. With the development of science and technology and social

progress, steel structures will continue to inno.

Material Description

Main Structure	Including Column & Beam, Made of welded H section Steel, Steel Grade Q355B/Q235B
	Column & Beam Connection: High Strength Bolt
	Column & Foundation Connection: Pre-embedded Anchor Bolt
Secondary Structure	Roof Purlin & Wall Purlin: C-shape or Z-shape Steel
	Knee Brace: Angle Steel
	Brace: Steel Rod
	Tie Bar: Steel Pipe

Types of wall panels and roof panels	Applicable Regions and Scenarios
Color Steel Sheet	Areas without winter, preferred for processing workshops and warehouses
Color Steel Sheet & Fiberglass Roll Insulation	Areas with winter but with low requirements of temperature , preferred for warehouses and workshops
Insulated Sandwich Panel	Workshops and warehouses with temperature requirements
PU Insulated Sandwich Panel	Workshops, warehouses and public facilities with high requirements of temperature for the working environment

Product packaging

FAQ

1. What kind of customer service do you provide?

We offer comprehensive customer service, including basic design,supporting facilities procurement, and the option to dispatch installation guidance.

2. How about the customer reviews of your company?

We are proud to have received consistently high five-star reviews from our customers, which stand as a testament to our commitment to quality and service.

3. What is your quality inspection process like?

Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished goods, each stage is meticulously inspected to guarantee superior quality.

4. Can you send engineers or a whole team to install my project?

We will give detailed installation drawings for free. We can send engineers as an installation director or a team upon request.

5. Do you accept container loading inspection?

You are welcomed to send an inspector, not only for the container loading, but any time during the production time.

6. Do you offer designing service for us?

Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial buildings like office mansions, super markets, auto dealer shops, shipping malls, 5-star hotels.

7. What is the delivery time?

Delivery time depends on order quantities. In general, the delivery time to the nearest seaport in China will be 40 days after receiving the deposit.

8. How can I get a quotation for my projects?

You can contact us by email, phone,  Trade manager and so on 24*7 and you will get a reply within 8 hours.

9. What certifications has your company passed?

Our company has passed professional certifications such as IOS9000, CE, and SGS, ensuring that our products and services meet international standards.
